White Halogen Free PI Film Coverlay

---

White Halogen Free PI Film Coverlay is an adhesiveness double-sided (D/S) metal-clad polyimide film, furnished in the form of roll laminate with RA or ED copper on both sides. ThinFlex-A adhesiveness D/S composites are designed for a wide variety of flexible circuit applications which require advanced material performance, temperature resistance, fine pitch, and high reliability.



Board Thickness: 0.07-0.40mm
Base Material: 0.5mil - 2mil Polyimide film
Copper Thickness: 0.5OZ-2OZ
Min. Line Width/ Spacing: 3mil (0.08mm)/3mil (0.08mm)
Coverlay: Yellow, White, Balck



特徵
Excellent dimensional stability
Excellent flexibility
Finer line etch ability
Low moisture absorption
Excellent flammability (Flame class UL 94V-0)
Excellent chemical resistance
Excellent thermal, mechanical, and electrical properties
